HYCS035130350BCC
Single Acting Cylinder w/Clevis, Clevis
Harken’s full range of cylinders are perfect for mast, sail, and keel controls. Cylinders include a standard clevis jaw on both ends, but can also be fitted with blocks and different eye types.
Technical specifications · Harken HYCS035130350BCC
| Stroke | 350 mm |
|---|---|
| Pin-to-pin length, closed | 609 mm |
| Weight | 1.88 kg |
| Cylinder diameter | 35 mm |
| Rod diameter | 13 mm |
| Maximum outside diameter | 49 mm |
Weight is for maximum stroke and includes fork ends. For open length, add stroke to the closed pin-to-pin length. Maximum working pressure: 345 bar; recommended pressure: 275 bar.
